rio — A lightweight job scheduler in Go with batteries included

What is RIO?

Rio is a lightweight job scheduler and job chaining library. Its mainly build for Golang web apps, but it can be very easily mold to serve any application needing job scheduling. The library is an asynchronous job processor, which makes all the backed calls asynchronously with retry, timeout and context cancellation functionality.

It also provides very easy semantics to join multiple data sources based on their output and input types, at the same time having no coupling between the data sources. This helps in creating new APIs or resolvers for GraphQL APIs a breeze.

Concern

Many times we write web apps which connects to different data sources, combines the data obtained from these sources and then do some more jobs. During these process, we do a lot of boilerplate to transform one data type to other. Also in the absence of a proper job scheduler, we create goroutines abruptly and without proper management. These create unmanageable code. To update those code is even more hard in future, when there is a new team member in the team.

Rio tries to solve this problem by introducing two concepts.

1. An asynchronous job processor

This is the piece which runs the multiple jobs asynchronously. It has a priority queue(balancer.go and pool.go) which hands off incoming requests to a set of managed workers.

The balancer is implemented by a min heap priority queue and when assigning a new task it checks the least loaded worker.

To implement the min heap we just need to implement 4 handy methods of the pool interface like this:

2. Easy management of these goroutines and chaining them

How many times do we do this:

call service 1 in goroutine 1
wait and get response from goroutine 1
call service 2 in goroutine 2, taking piece of data from service call 1
wait and get response from goroutine 2
call service 3 in goroutine 3, taking piece of data from service call 3
wait and get response from goroutine 3

You get the idea, this only delays thing more and does a lot of context switching. Rio helps in this, by chaining multiple calls together by means of using closures and function types and runs in one goroutine.

Now many can think is it not going to be slower compared to doing multiple goroutine calls.

Let’s see.

Think of the previous example. If you do not get response from service 1, can you invoke service 2, or if service 2 fails, can you call service 3? No right, as there is data dependency between these calls.

Rio chains dependent jobs together by introducing this pattern.

request := rio.BuildRequests(context,
          (<callback of service 1>.WithTimeOut(100 ms).WithRetry(3))
          .FollowedBy(<function for transforming data from service 1 response to request or partial request of 2>,
                      <callback of service 2>)
          .FollowedBy(<function for transforming data data from service 2 response to request or partial request of 3>,
                                  <callback of service 3>)

Let’s see an example

Once the chaining is done in line 10, we are posting the jobs like this

balancer.PostJob(request)

And finally waiting for the chain to complete

<-request.CompletedChannel

Once the call chain happens, the request comes back with responses for all these calls in a slice and we can do this

• Only one job response

request.GetOnlyResponse()

• Multiple job response

request.GetResponse(index) //---0,1,2

If any job fails, the response will be empty response, specifically rio.EMPTY_CALLBACK_RESPONSE

Watch out for the full example in the example folder if anyone wants to use it.

Thanks !!!
