Pooling Layer Explained and its Importance in CNN

Pooling layers are used in CNN to reduce the spatial dimensions while still capturing the important features. The pooling layers are applied to the feature maps obtained from convolutional layers in order to reduce their dimensions. You can read more about CNN here and here:

There are three main types of pooling layers:

(1) Max Pooling: Select the maximum value within the analyzed region (pooling window). By keeping the maximum activation it retains the most significant feature in each region.

(2) Average Pooling: As the name suggests, calculates the average value for each region. This approach is useful if we aim to preserve the general intensity of features rather than capturing specific details.

(3) Global Pooling: This can be global max pooling or global average pooling. With global pooling, the entire feature map is considered and reduced instead of its regions. It is useful when the global context is more important than spatial features.

We can compress a feature map in CNN by increasing the stride length in convolutional layers and/or by applying pooling layers.

The pooling layers operate with each individual feature map. So, if the previous convolutional layer has 98 kernels, and a feature map size of 32, the output will be 32x32x98. If we apply a pooling layer with a pooling window 3x3 and a fixed stride of the same size 3, the feature size will be:

Output = ((32–3)/3) + 1 = 11

So the final output size for the given pooling layer is 11x11x98.
