CronJob K8s in .NET: the right way

🟩🟩🟩 Expert

Disclaimer: assuming your familiarity with CronJob K8s’ existence and benefits, I’d rather concentrate on the development part instead of delving into specifics, which could be time-consuming.

Why this choice?

There are several libraries to perform background processing in .NET, such as Quartz or Hangfire. You can also manage it yourself with a BackgroundService. So why choose a CronJob K8s?

• Avoiding job concurrency: Even if there are some limitations, K8s is pretty good at preventing concurrent job execution without relying on a database.
• Monitoring: You benefit from the whole ecosystem around Kubernetes (like Prometheus) to detect as quickly as possible an error during execution. You can configure the number of pods in error to keep during the analysis of the problem.
• Centralizing all your jobs in the same Docker image and Git repository, not only does make maintenance easier but also streamlines the development process.

As light as possible

Consider an existing solution composed of an empty “console app” project named Runner.csproj.

For this project, we’ll only use the .NET Runtime Docker image instead of the ASP.NET in my other stories to prove that we don’t need to pull many dependencies to build a CronJob.

Since we don’t depend on ASP.NET, which typically includes pre-installed dependencies, we must add some required ones manually in our .csproj file.

Choose your strategy

⚠️ This paragraph will call upon notions described in this story that are necessary for the proper understanding of the following.

We are ready to start implementing our background processor. The goal is to centralize all our jobs in the same project. It would be nice to reduce the workload when adding a future process.

Consider using the “Strategy” design pattern to execute only the necessary code associated with the scheduled job in our CronJob. First of all, we need an interface to impose the choice of a type of job to execute, let’s name it “IJobProcessor”.

public interface IJobProcessor
{
    Job JobToProcess { get; }
    Task Execute();
}

Adding a common log feature to each job can be achieved by incorporating an abstract class, though it is not mandatory.

public abstract class JobProcessorBase : IJobProcessor
{
    ...

    public async Task Execute()
    {
        Stopwatch stopwatch = Stopwatch.StartNew();
        _logger.LogInformation("{JobToProcess} started", JobToProcess.ToString());

        await Process();

        stopwatch.Stop();
        _logger.LogInformation("{JobToProcess} ended, elapsed time: {ElapsedMilliseconds} ms", JobToProcess, stopwatch.ElapsedMilliseconds);
    }
}

And finally, we have to implement our job. For our example, I will call an endpoint and log whether or not its health check is valid. This example has no business value. You can imagine a report generation process or anonymization to be compliant with the GDPR.

We are now ready to finalize our CronJob. We have to use our strategy pattern. We’ll inject it into the “Program.cs” Main function to retrieve environment variables, including the job type for execution. The objective is to ensure that a return value of 0 means the job succeeds of the job, while a return value of 1 signifies failure. This convention enables K8s to accurately flag the current execution as a success or a failure.

You can run an execution of a specific job by updating the docker-compose.yml file.

version: '3.7'

services:
  runner:
    image: runner:${TAG:-latest}
    environment:
      # specify the job type to execute
      - JOB=TestJob
      # add other configuration variables
      - TEST_ENDPOINT_BASE_URL=https://sample-service.com/
    build:
      context: .
      dockerfile: Runner/Dockerfile

Don’t forget to test!

The setup for my integration tests closely looks like the one in the story: Integration Testing in .NET: the right way. I recommend referring to it to avoid burdening my explanations.

To maintain the project’s structure, you can use an architecture test (using ArchUnitNET) to ensure that all implementations of JobProcessorBase reside in the same namespace.

    [Fact]
    public void Classes_that_reside_in_Jobs_namespace_should_be_assignable_to_JobProcessorBase()
    {
        // arrange act assert
        Classes().That().ResideInNamespace("Runner.Core.UseCases.Jobs").Should().BeAssignableTo("Runner.Core.UseCases.Jobs.JobProcessorBase").Check(Architecture);
    }

Testing the “Program.cs” can be challenging, so it’s more convenient to test your use cases directly via dependency injection. Here’s an example that enables you to validate your HTTP calls and the conformity of your log entries.

Time to schedule!

We are building a CronJob and still haven’t talked about scheduling. That’s pretty strange, right? The scheduling is not managed at the code level but during the deployment on K8s. While you can create your deployment.yml file directly, I recommend using a Helm chart for better maintainability. Below is an example of a configuration file to integrate into a Helm chart to deploy a CronJob that runs a Docker image corresponding to the code discussed earlier.

Conclusion

Tic, tac, tic, tac 🕑, job is done! You have successfully built a CronJob K8s in .NET while remaining as light as possible.

From now on, it will become essential to add a monitoring layer to ensure that your jobs are running smoothly.

You can access the entire source code of this post on GitHub, stay tuned!
