Backtest your Trading Systems with Python — Strategies Development

We’ve seen previously how you can extract data and create the most simple strategy using backtrader (if you’ve missed this story: Backtest your Trading Systems with Python — Introduction). We will now see how to develop complex strategies.

Strategy’s skeleton

Below is the skeleton of any strategy:

import backtrader as bt

class MyStrategy(bt.Strategy):
    params = (
    )

    def __init__(self):
        pass

    def log(self, msg, dt=None):
        pass

    def next(self):
        pass

    def notify_order(self, order):
        pass

    def notify_trade(self, trade):
        pass

• params: strategy’s parameters.
• init: strategy’s constructor, useful for indicator’s initialization.
• log: method you can use to display text.
• next: method executed for each iteration.
• notify_order: method executed when an order is created or updated.
• notify_trade: method executed when a trade is created or updated.

Indicators

Maybe you want to use indicators in your strategies. Gratefully, backtrader has some basic indicators available such as RSI, MACD, EMA, etc… If you want custom indicators you can develop yours, but we’ll see that later.

You need first to import the indicators you want to use, for example, an EMA.

from backtrader.indicators import ExponentialMovingAverage as EMA

Then, you can initialize them in your strategy’s constructor:

def __init__(self):
   self.ema = EMA(period=10)

As you can see, we can specify parameters for indicators.

Then, if we need the value of our ema in the next method of our strategy, we can get it the same way as we get the close price. We want to get the ema line of our ema attribute:

ema_now = self.ema.ema[0]

If we want the ema one bar earlier:

ema_earlier = self.ema.ema[-1]

For a full indicators reference, check https://www.backtrader.com/docu/indautoref/.

Parameters

It’s useful to parameterize our strategies, either for optimization or just for trying things. We can specify parameters in the params attribute.

class MyStrategy(bt.Strategy):
    params = (
        ('ema_period', 10),
    )

A parameter is a tuple whose first element is the parameter’s name, and the second element is a default value.

Then we can access our parameter anywhere in our strategy using self.p:

def __init__(self):
   self.ema = EMA(period=self.p.ema_period)

We specify the value of a parameter when initializing our strategy:

cerebro.addstrategy(MyStrategy, ema_period=10)

Rules

To define our strategy’s rules, we use the next method.

def next(self):
    if self.datas[0].close[0] < self.ema.ema[0]:
        # do something

Orders

To deal with orders, we first have to initialize an empty list in our strategy’s constructor:

def __init__(self):
    self.orders_ref = list()

Now, we have to implement notify_order :

def notify_order(self, order):
    if not order.alive() and order.ref in self.orders_ref:
    self.orders_ref.remove(order.ref)

This way, when an order is created or updated, we check if the order is still alive. If he’s not, we remove it.

Then, we have to create orders when our strategy’s signals are triggered. To make things easy, we will begin with just a simple buy order:

def next(self):
    if self.datas[0].close[0] < self.ema[0]:
        orders = [self.buy()]
        self.orders_ref = [order.ref for order in orders if order]

    if self.datas[0].close[0] > self.ema[0]:
        self.close()

We use self.buy() to buy and self.sell() to sell. self.close() closes our orders.

If we want to make things more complex, we can use OCO orders:

orders = self.buy_bracket(price=ACTUAL_PRICE, stopprice=stop_price, limitprice=take_profit_price)

We can also use stop or limit orders:

orders = [self.buy(), self.sell(exectype=bt.Order.Stop, price=stop_price)]
# or
orders = [self.buy(), self.sell(exectype=bt.Order.Limit, price=take_profit_price)]

Mixing everything

Now, we can complete our strategy’s skeleton using everything we know:

class MyStrategy(bt.Strategy):
    params = (
        ('ema_period', 10),
    )

    def __init__(self):
       self.ema = EMA(period=self.p.ema_period)

    def log(self, msg, dt=None):
        print("{} - {}".format(dt or self.datas[0].datetime.date(0), msg))
    def next(self):
        self.log('{} - {} {} @ {}'.format(self.datas[0].datetime.date(0), self.datas[0].close[0], self.datas[0]._name, self.ema[0]))
        if self.datas[0].close[0] < self.ema[0]:
            orders = [self.buy()]
            self.orders_ref = [order.ref for order in orders if order]

        if self.datas[0].close[0] > self.ema[0]:
            self.close()

    def notify_order(self, order):
        self.log('{} - {} {} @ {}'.format(order.data._name, order.size, order.data._name, order.price))
        if not order.alive() and order.ref in self.orders_ref:
            self.orders_ref.remove(order.ref)

    def notify_trade(self, trade):
        self.log('{} - {} {} @ {}'.format(trade.dt.date(0), trade.size, trade.data._name, trade.price))

And we can run our strategy:

btc_eur = yf.Ticker("BTC-EUR")
data = btc_eur.history()
pandas_data = btfeeds.PandasData(dataname=data)

cerebro.adddata(pandas_data)
cerebro.addstrategy(MyStrategy, ema_period=200)

cerebro.run()

Your strategy will be backtested and you should see some data getting logged.

Then?

Then, nothing happens because we don’t use any analyzer. We’ll see in the next story how to use them to analyze your strategy’s results. In the meantime, you can add a line for cerebro.plot()after cerebro.run() . It will display your strategy’s chart.

Be sure to follow me so you don’t miss the next story about Backtesting your Trading Systems with Python!

Edit: find the next story here: https://readmedium.com/backtest-your-trading-systems-with-python-analysis-of-the-results-467a82b26ef5
