Abstract
self, img</span>):
height, width, channels = img.shape
results = self.model.predict(source=img.copy(), save=<span class="hljs-literal">False</span>, save_txt=<span class="hljs-literal">False</span>)
result = results[<span class="hljs-number">0</span>]
segmentation_contours_idx = []
<span class="hljs-keyword">for</span> seg <span class="hljs-keyword">in</span> result.masks.segments:
<span class="hljs-comment"># contours</span>
seg[:, <span class="hljs-number">0</span>] *= width
seg[:, <span class="hljs-number">1</span>] *= height
segment = np.array(seg, dtype=np.int32)
segmentation_contours_idx.append(segment)
bboxes = np.array(result.boxes.xyxy.cpu(), dtype=<span class="hljs-string">"int"</span>)
class_ids = np.array(result.boxes.cls.cpu(), dtype=<span class="hljs-string">"int"</span>)
scores = np.array(result.boxes.conf.cpu(), dtype=<span class="hljs-string">"float"</span>).<span class="hljs-built_in">round</span>(<span class="hljs-number">2</span>)
<span class="hljs-keyword">return</span> bboxes, class_ids, segmentation_contours_idx, scores</pre></div><h2 id="1088">4. Interpreting the codes</h2><p id="3a87">Let’s run the code and try to interpret it.</p><p id="cbca">It shows the size of image is 448x640 of class frisbee or sports ball</p><div id="6b8d"><pre><span class="hljs-keyword">for</span> bbox, class_id, seg, score <span class="hljs-keyword">in</span> zip(bboxes, classes, segmentations, scores):
cv2.rectangle(img,(x,y), (x2, y2),(0,0,255),2)
<span class="hljs-built_in">print</span>(bboxes)</pre></div><figure id="f0ba"><img src="https://cdn-images-1.readmedium.com/v2/resize:fit:800/1*H07F26athuNmWdqS6zYATQ.png"><figcaption></figcaption></figure><p id="b4ce"><b>5. Draw the Bounding Box</b></p><p id="dc45">Let’s draw the bounding box to ensure we have the correct object.</p><div id="faa6"><pre>for bbox, class_id, seg, score in <span class="hljs-built_in">zip</span>(bboxes, classes, segmentations, scores):
cv2.<span class="hljs-built_in">rectangle</span>(img,(x,y), (x2, y2),(<span class="hljs-number">0</span>,<span class="hljs-number">0</span>,<span class="hljs-number">255</span>),<span class="hljs-number">2</span>)</pre></div><figure id="e4d1"><img src="https://cdn-images-1.readmedium.com/v2/resize:fit:800/1*Wd8CPiRMeTM8-X5dUjT5FA.png"><figcaption></figcaption></figure><p id="8507"><b>6. Draw polylines</b></p><p id="fa79">Here is the opencv format: <code>cv2.polylines(image, [pts], isClosed, color, thickness)</code></p><div id="2616"><pre>for bbox, class_id, seg, score in <span class="hljs-built_in">zip</span>(bboxes, classes, segmentations, scores):
cv2.<span class="hljs-built_in">rectangle</span>(img,(x,y), (x2, y2),(<span class="hljs-number">0</span>,<span class="hljs-number">0</span>,<span class="hljs-number">255</span>),<span class="hljs-number">2</span>)
cv2.<span class="hljs-built_in">polylines</span>(img,[seg], True, (<span class="hljs-number">255</span>,<span class="hljs-number">0</span>,<span class="hljs-number">0</span>), <span class="hljs-number">2</span>)</pre></div><figure id="186d"><img src="https://cdn-images-1.readmedium.com/v2/resize:fit:800/1*JBl0ztp8GVsxdxv6kbufNg.png"><figcaption></figcaption></figure><p id="37d3"><b>7. Display class_id in the images</b></p><div id="f77a"><pre>for bbox, class_id, seg, score in <span class="hljs-built_in">zip</span>(bboxes, classes, segmentations, scores):
cv2.<span class="hljs-built_in">rectangle</span>(img,(x,y), (x2, y2),(<span class="hljs-number">0</span>,<span class="hljs-number">0</span>,<span class="hljs-number">255</span>),<span class="hljs-number">2</span>)
cv2.<span class="hljs-built_in">polylines</span>(img,[seg], True, (<span class="hljs-number">255</span>,<span class="hljs-number">0</span>,<span class="hljs-number">0</span>), <span class="hljs-number">2</span>)
cv2.<span class="hljs-built_in">putText</span>(img,<span class="hljs-built_in">str</span>(class_id), (x, y-<span class="hljs-number">10</span>), cv2.FONT_HERSHEY_PLAIN, <span class="hljs-number">2</span>, (<span class="hljs-number">0</span>,<span class="hljs-number">0</span>,<span class="hljs-number">255</span>),<span class="hljs-number">2</span>)</pre></div><figure id="541f"><img src="https://cdn-images-1.readmedium.com/v2/resize:fit:800/1*9u3k7CZJoWD0J8SFHr20kg.png"><figcaption></figcaption></figu
Options
re><h2 id="1682">8. To fill the shape, just use FillPoly</h2><div id="5f1b"><pre>for bbox, class_id, seg, score in <span class="hljs-built_in">zip</span>(bboxes, classes, segmentations, scores):
cv2.<span class="hljs-built_in">rectangle</span>(img,(x,y), (x2, y2),(<span class="hljs-number">0</span>,<span class="hljs-number">0</span>,<span class="hljs-number">255</span>),<span class="hljs-number">2</span>)
cv2.<span class="hljs-built_in">polylines</span>(img,[seg], True, (<span class="hljs-number">255</span>,<span class="hljs-number">0</span>,<span class="hljs-number">0</span>), <span class="hljs-number">2</span>)
cv2.<span class="hljs-built_in">putText</span>(img,<span class="hljs-built_in">str</span>(class_id), (x, y-<span class="hljs-number">10</span>), cv2.FONT_HERSHEY_PLAIN, <span class="hljs-number">2</span>, (<span class="hljs-number">0</span>,<span class="hljs-number">0</span>,<span class="hljs-number">255</span>),<span class="hljs-number">2</span>)
cv2.<span class="hljs-built_in">fillPoly</span>(img, pts=[seg], color=(<span class="hljs-number">255</span>, <span class="hljs-number">0</span>, <span class="hljs-number">0</span>))</pre></div><figure id="6535"><img src="https://cdn-images-1.readmedium.com/v2/resize:fit:800/1*5nI1CNwifDKx7yKpFwDovw.png"><figcaption></figcaption></figure><p id="fe5c"><b>9. Load in our own image now</b></p><p id="1255">Now add in the our own weights and image to the pycharm</p><figure id="5e22"><img src="https://cdn-images-1.readmedium.com/v2/resize:fit:800/1*885EJtYZDG9W9AQDeGFCOQ.png"><figcaption></figcaption></figure><p id="08b7">Change the following codes</p><p id="5651">img = cv2.imread(“rugby.jpg”)</p><p id="7436">→ img = cv2.imread(“container.jpg”)</p><p id="ecdc">ys = YOLOSegmentation(‘yolov8m-seg.pt’)</p><p id="00de">→ ys = YOLOSegmentation(‘best.pt’)</p><div id="95c2"><pre><span class="hljs-attr">img</span> = cv2.imread(<span class="hljs-string">"rugby.jpg"</span>)
<span class="hljs-attr">ys</span> = YOLOSegmentation(<span class="hljs-string">'yolov8m-seg.pt'</span>)</pre></div><div id="e1a1"><pre><span class="hljs-attr">img</span> = cv2.imread(<span class="hljs-string">"container.jpg"</span>)
<span class="hljs-attr">ys</span> = YOLOSegmentation(<span class="hljs-string">'best.pt'</span>)</pre></div><p id="09db"><b>10. Test the image</b></p><p id="5b61">Here are the test results in Pycharm. According to data.yaml file, the class id is 0 (blue), 1(gray), 2(green), 3(red) and 4(yellow)</p><figure id="03b8"><img src="https://cdn-images-1.readmedium.com/v2/resize:fit:800/1*nzDJrIVpkXtXb4pDO5mtvg.png"><figcaption></figcaption></figure><figure id="55a6"><img src="https://cdn-images-1.readmedium.com/v2/resize:fit:800/1*rmGcevWHaCQ18iCRO5Pifw.png"><figcaption></figcaption></figure><p id="ac3e"><b>9.1 scores</b></p><p id="c2ac">The scores are following the sequence in Roboflow which is generated into a data.yaml file.</p><figure id="ad6d"><img src="https://cdn-images-1.readmedium.com/v2/resize:fit:800/1*BgCDYQ8n37iHXgOdbzM5pw.png"><figcaption></figcaption></figure><p id="4b1f">We see that there is a duplicate gray colour with the left side considered as a gray object</p><p id="7364"><b>9.2 Scores</b></p><p id="ff1d">Scores show relatively detection scores are high for blue and yellow. The worst score is gray since there are overdetected one of them.</p><figure id="effc"><img src="https://cdn-images-1.readmedium.com/v2/resize:fit:800/1*Kdy0tXlZunTzuRsoRHkCGw.png"><figcaption></figcaption></figure><h2 id="17ec">10. Now convert to TFLite model</h2><p id="2632">To convert to TFlite model, just run the following command</p><p id="b5cc">!yolo export model=/content/runs/segment/train2/weights/best.pt format=tflite</p><h1 id="279c">Conclusion</h1><p id="8788">As you can see, we can get more precise location and bounding boxes with object segmentation. Try this out and see if you can use it with other OpenCV function!</p><h1 id="daa2">References</h1><p id="30d7">Ref1:<a href="https://nirmalamurali.medium.com/image-classification-vs-semantic-segmentation-vs-instance-segmentation-625c33a08d50">https://nirmalamurali.medium.com/image-classification-vs-semantic-segmentation-vs-instance-segmentation-625c33a08d50</a></p><p id="d045">Ref2:<a href="https://pysource.com/2023/02/21/instance-segmentation-yolo-v8-opencv-with-python-tutorial/">https://pysource.com/2023/02/21/instance-segmentation-yolo-v8-opencv-with-python-tutorial/</a></p></article></body>
