PYTHON — Creating Colored Matrix in Python

Digital design is like painting, except the paint never dries. — Neville Brody

# Creating a Colored Matrix in Python

One of the most visually appealing types of visualizations is a heatmap. Although matplotlib does not have a direct method for creating heatmaps, we can still generate a grid of colored squares from a two-dimensional ndarray. To get started, we need to import the make_axes_locatable function from mpl_toolkits.

from mpl_toolkits.axes_grid1.axes_divider import make_axes_locatable

We’ll create two separate two-dimensional ndarrays, similar to matrices, to demonstrate the process of creating a colored matrix.

import matplotlib.pyplot as plt
import numpy as np

# Create two 10x10 arrays
x = np.diag(np.arange(2, 12))[::-1]
x2 = np.arange(100).reshape(10, 10)

# Disable tick marks and numeric labels
nolabels = {i: j for i, j in zip('xy', ['top', 'right'])}
nolabels.update({i: False for i in ['top', 'bottom', 'left', 'right']})

# Plot the data
with plt.rc_context({'axes.grid': False}):
    fig, (ax1, ax2) = plt.subplots(1, 2)
    cax = ax1.matshow(x, cmap='viridis')
    ax2.matshow(x2, cmap='RdYlGn_r')

    for ax in [ax1, ax2]:
        ax.tick_params(axis='both', which='both', **nolabels)

    for i, j in zip(*x.nonzero()):
        ax1.text(j, i, x[i, j], color='white', ha='center', va='center')

    divider = make_axes_locatable(ax2)
    cax = divider.append_axes("right", size="5%", pad=0.1)
    plt.colorbar(cax=cax)

    fig.suptitle('Heatmaps with Axes.matshow', fontsize=16)
    plt.show()

In this example, we first create two 10x10 arrays, x and x2, to represent the data that we want to visualize. We then use the matplotlib and numpy libraries to plot these arrays as color-coded matrices using the matshow function.

Additionally, we disable the tick marks and labels on the axes to create a cleaner visualization, and we add text labels to the diagonal color strips to provide more context to the visualization. Lastly, we include a color bar to indicate the color mapping of the data values.

The end result is a grid of colored squares representing the provided data, and the code provides a clear and detailed explanation of each step involved in creating the colored matrix.
