How to Deploy AWS Directory Service using Terraform

AWS Directory Service provides multiple ways to use Microsoft AD (Active Directory) with other AWS services. Directories store information about users, groups, and devices, and administrators use them to manage access to information and resources.

AWS Directory Service provides multiple directory choices for customers using existing Microsoft AD or LDAP (Lightweight Directory Access Protocol)–aware applications in the cloud. It also offers those same choices to developers who need a directory to manage users, groups, devices, and access.

In this story, we will deploy AWS Directory Service using Terraform.

Active Directory in Cloud Environments

This story is part of my Active Directory in Cloud Environments series.

I have been deploying Active Directory in AWS, Azure, GCP, and OCI cloud environments for +10 years. I have been using AD since Microsoft launched the public beta in 1999, so this is one of my favorite subjects to write about.

How to Deploy AWS Directory Service using Terraform (this story)
How to Deploy Active Directory (AD) Domain Controller (DC) Virtual Machine (VM) in Azure with Terraform
How to Deploy Azure Active Directory (AD) Domain Services with Terraform
Automating Microsoft AD and DNS with Terraform & KopiCloud AD API
How to Create and Manage AD Users with Terraform

Network Requirements

To deploy AWS Directory Service, we will need a VPC with at least two subnets located in two separate AZ (Availability Zones).

We can start with a simple Terraform code to create the VPC and subnets or use the VPC Module to create our network.

Code to create a VPC and Subnet

resource "aws_vpc" "directory_service_vpc" {
  cidr_block = "10.10.0.0/16"
}

resource "aws_subnet" "directory_service_subnet_1" {
  vpc_id            = aws_vpc.directory_service_vpc.id
  availability_zone = "eu-west-1a"
  cidr_block        = "10.10.1.0/24"
}

resource "aws_subnet" "directory_service_subnet_2" {
  vpc_id            = aws_vpc.directory_service_vpc.id
  availability_zone = "eu-west-1b"
  cidr_block        = "10.10.2.0/24"
}

In this story, we will use the VPC Module to create a simple VPC with two public and two private subnets in the EU-West region.

module "vpc" {
  source = "terraform-aws-modules/vpc/aws"
  name   = "kopicloud-dev"
  cidr   = "10.10.0.0/16"

  azs             = ["eu-west-1a", "eu-west-1b"]
  private_subnets = ["10.10.1.0/24", "10.10.2.0/24"]
  public_subnets  = ["10.10.3.0/24", "10.10.4.0/24"]

  enable_nat_gateway     = true
  single_nat_gateway     = true
  one_nat_gateway_per_az = false

  enable_dns_hostnames = true
  enable_dns_support   = true

  tags = {
    Name        = "kopicloud-dev"
    Environment = "Development"
  }
}

AWS Directory Service Versions

AWS Directory Service is offered in 3 different flavors: SimpleAD, ADConnector, or MicrosoftAD.

SimpleAD is a standalone managed directory that is powered by a Samba 4 Active Directory Compatible Server. It is available in two sizes.
ADConnector is a directory gateway with which we can redirect directory requests to our on-premises Microsoft Active Directory without caching any information in the cloud.
MicrosoftAD is a Microsoft Active Directory (AD) running on AWS-managed infrastructure.

AWS Directory Service Simple AD

SimpleAD is a standalone managed directory powered by a Samba 4 Active Directory Compatible Server. It is available in two sizes:

Small — Supports up to 500 users (approximately 2,000 objects, including users, groups, and computers).
Large — Supports up to 5,000 users (approximately 20,000 objects, including users, groups, and computers).

resource "aws_directory_service_directory" "simple_ad" {
  name     = "dev.kopicloud.local"
  password = "Sup3rS3cr3tP@ssw0rd"
  size     = "Small"

  vpc_settings {
    vpc_id     = module.vpc.vpc_id
    subnet_ids = module.vpc.private_subnets
  }

  tags = {
    Name        = "kopicloud-simple-ad"
    Environment = "Development"
  }
}

AWS Directory Service AD Connector

ADConnector is a directory gateway with which we can redirect directory requests to our on-premises Microsoft Active Directory without caching any information in the cloud.

We can use AD Connector if we only need to allow our on-premises users to log in to AWS applications and services with their Active Directory credentials.

We can also use AD Connector to join Amazon EC2 instances to our existing Active Directory domain.

Note: There are a few extra requirements to use the AD Connector:

The VPC must be connected to your existing network through a virtual private network (VPN) connection or AWS Direct Connect.
The VPC must have default hardware tenancy.
No network overlapping between the on-premise network and the AWS VPC is allowed.

The AD Connector comes in two sizes:

Small — designed for organizations up to 500 users.
Large — designed for organizations up to 5000 users.

resource "aws_directory_service_directory" "ad_connector" {
  name     = "dev.kopicloud.local"
  password = "Sup3rS3cr3tP@ssw0rd"
  size     = "Small"
  type     = "ADConnector"

  connect_settings {
    customer_dns_ips  = ["10.20.1.10", "10.20.1.20"]
    customer_username = "ADAdmin"
    vpc_id            = module.vpc.vpc_id
    subnet_ids        = module.vpc.private_subnets
  }

  tags = {
    Name        = "kopicloud-ad-connector"
    Environment = "Development"
  }
}

AWS Directory Service Microsoft AD

MicrosoftAD is a Microsoft Active Directory (AD) running on AWS-managed infrastructure.

This service creates a highly available pair of Windows domain controllers connected to our virtual private cloud (VPC). Each of these domain controllers runs in different AZ (Availability Zones).

This is a fully managed service, and AWS provides host monitoring and recovery, data replication, snapshots, and software updates and it is available in two sizes:

Standard Edition — is optimized to be a primary directory for small and midsize businesses with up to 5,000 employees. It provides you enough storage capacity to support up to 30,000 directory objects, such as users, groups, and computers.
Enterprise Edition — is designed to support enterprise organizations with up to 500,000 directory objects.

resource "aws_directory_service_directory" "aws-managed-ad" {
  name        = "kopicloud.local"
  description = "KopiCloud Managed Directory Service"
  password    = "Sup3rS3cr3tP@ssw0rd"
  edition     = "Standard"
  type        = "MicrosoftAD"

  vpc_settings {
    vpc_id     = module.vpc.vpc_id
    subnet_ids = module.vpc.private_subnets
  }

  tags = {
    Name        = "kopicloud-managed-ad"
    Environment = "Development"
  }
}

And that’s all, folks. If you liked this story, please show your support by 👏 this story. Thank you for reading!
