8. Coloring Graph With K Colors

Question: Find if an undirected graph can be colored with a maximum of K colors, two adjacent vertices should not have the same color.

For example, given

[
  [1, 1, 1, 0, 1],
  [1, 1, 1, 0, 1],
  [1, 1, 1, 0, 1],
  [1, 1, 1, 0, 1],
  [1, 1, 1, 0, 1]
]

and k: 3, you should return nil,

and k: 4, you should return [1, 2, 3, 4, 4].

Hints:

- You need a collection to track what colors are set for all nodes,

- Set the color for one node, then do it recursively for the next node,

- This is a backtracking problem.

Solution:

func coloringGraph(k: Int, graph: [[Int]]) -> [Int]? {
    // 1.
    guard k > 0 else { return nil }
    guard !graph.isEmpty else { return [] }

    // 2.
    var colors = Array(repeating: 0, count: graph.count)
    let result = coloringGraph(k: k, graph: graph, colors: &colors, vertex: 0)

    // 3.
    return result ? colors : nil
}

func coloringGraph(k: Int, graph: [[Int]],
                   colors: inout [Int], vertex: Int) -> Bool {
    // 4.
    guard vertex < graph.count else { return true }
    for color in 1...k {
        // 5.
        if isSafe(vertex: vertex,
                  color: color,
                  graph: graph,
                  colors: colors) {
            colors[vertex] = color
            return coloringGraph(k: k,
                                 graph: graph,
                                 colors: &colors,
                                 vertex: vertex + 1)
        }
    }
    return false
}

func isSafe(vertex: Int, color: Int, graph: [[Int]], colors: [Int]) -> Bool {
    guard vertex < graph.count, vertex < colors.count else { return false }
    // 6.
    let neighbors = graph[vertex]
    // 7.
    for i in 0..<neighbors.count {
        if neighbors[i] == 1, colors[i] == color {
            return false
        }
    }
    return true
}

Explanations:

1. Check if k is not 0 or the graph is not empty.

guard k > 0 else { return nil }
guard !graph.isEmpty else { return [] }

2. Let’s create the array which will hold the colors and start the recursion.

var colors = Array(repeating: 0, count: graph.count)
let result = coloringGraph(k: k, graph: graph, colors: &colors, vertex: 0)

3. If the result is true, there is a way to color the graph with only k colors; let’s return the color array.

return result ? colors : nil

4. As we are recursing, we need a base case; here, if the vertex index is greater or equal to the number of vertices, it means we have treated all vertices, then it means we can color the graph with k colors.

guard vertex < graph.count else { return true }

5. It’s here where the magic happens; we are backtracking all colors for all nodes. For all nodes, we will try all colors; if we find a color that “is safe to use” (not used by any neighbors), we save the color for the current node and recurse with the subsequent nodes; if no colors match (neighbors have used all colors) we return false as we cannot use k colors for this graph.

for color in 1…k {
  if isSafe(vertex: vertex, color: color, graph: graph, colors: colors) {
    colors[vertex] = color
    return coloringGraph(k: k, graph: graph, colors: &colors, vertex: vertex + 1)
  }
}

6. Let’s find the neighbors of the given node.

let neighbors = graph[vertex]

7. if no neighbor is using the current color, this color is safe to use for this number.

for i in 0..<neighbors.count {
  if neighbors[i] == 1, colors[i] == color {
    return false
  }
}
return true

Complexity:

- Time Complexity: As in the worst case will be trying all color combinations; the time complexity is O(k^n), where k is the number of colors and n is the number of nodes within the graph,

- Space Complexity: As we keep the color array by the size of the number of nodes/vertices O(n), but also the call stack for the backtracking will be up to n calls O(n), the space complexity is O(n) where n is the number of nodes within the graph.

Test-cases:

public func testColoringGraph() {
    var graph = [
        [1, 1, 1, 0, 1],
        [1, 1, 1, 0, 1],
        [1, 1, 1, 0, 1],
        [1, 1, 1, 0, 1],
        [1, 1, 1, 0, 1]
    ]

    assert(coloringGraph(k: 3, graph: graph) == nil, "coloringGraph 1 not equal")
    assert(coloringGraph(k: 4, graph: graph) == [1, 2, 3, 4, 4], "coloringGraph 2 not equal")

    graph = [
        [0, 1,  1, 1, 1],
        [1, 0,  0, 1, 0],
        [1, 1,  1, 0, 1],
        [1, 0,  0, 1, 0],
        [1, 0,  0, 1, 0]
    ]

    assert(coloringGraph(k: 2, graph: graph) == nil, "coloringGraph 3 not equal")
    assert(coloringGraph(k: 3, graph: graph) == [1, 2, 3, 2, 3], "coloringGraph 4 not equal")
    assert(coloringGraph(k: 4, graph: graph) == [1, 2, 3, 2, 3], "coloringGraph 5 not equal")
}

Follow-up:

Give the minimum K colors to color a given graph.
