Algorithms for Interview 2: Monotonic Stack

Introduction

Monotonic Stack is a special variation of the typical data structure Stack and appeared in many interview questions.

As its name shows, monotonic stack contains all features that a normal stack has and its elements are all monotonic decreasing or increasing.

When to Use Monotonic Stack

Monotonic Stack is the best time complexity solution for many “range queries in an array” problems. Because every element in the array could only enter the monotonic stack once, the time complexity is O(N). (N represents the length of the array).

For every “range query” problem, it could be sure to maintain a range using a normal array/list. However, we will do many repetitive operations to get information from every range. The time complexity is very high and the solution is always not good enough to pass an interview.

Using monotonic stack to maintain a range can save lots of time. Because it only updates information within the range based on new adding elements and avoids repetitive operations of existing elements. To be more precisely, the monotonic stack helps us maintain maximum and and minimum elements in the range and keeps the order of elements in the range. Therefore, we don’t need to compare elements one by one again to get minima and maxima in the range. At mean while, because it keeps the elements’ order, we only need to update the stack based on newest adding element.

The concept of monotonic stack, which is just a stack keeping monotonic, is not difficult to understand. But the hardest part is how to use this data structure to model and solve problems. No one will tell you that a problem should use monotonic stack in a real interview. Sometime it’s not obvious which solution is best for a problem if you are not familiar with many techniques and example problems. If a problem is suitable to use monotonic stack, it must has at least three characters:

1. It is a “range queries in an array” problem.
2. The minima/maxima element or the monotonic order of elements in a range is useful to get answer of every range query.
3. When a element is popped from the monotonic stack, it will never be used again.

Let’s have a look at some classic problems solved by monotonic stack:

Example Interview Problem 1:

This problem is from LeetCode 84. Largest Rectangle in Histogram.

Firstly, it looks like a range query problem. We maintain an monotonic increasing stack called mono_stack . When we meet a new height:

• If this height is higher than or equal to the last height in mono_stack, we just add it to the mono_stack.
• If this height is lower than the last height in mono_stack, we must pop the last height of mono_stack to keep the monotone.

The hardest operation happens at the second situation. As our rule 3: When a element is popped from the monotonic stack, it will never be used again. If we pop the last height, it should be totally thrown away and never added to stack again. If not, we cannot ensure that every item is added to the monotonic stack once and so the time complexity of the monotonic stack is not equal to O(N).

Therefore, when pop an item, we should calculate the largest possible rectangle it can generate and update the ret value. When we generate its largest possible rectangle, we meet rule 2 (The minima/maxima element or the monotonic order of elements in a range is useful to get answer of every range query.). Because of the monotone of the stack, we can get the leftmost and rightmost indexes which the popping item can “use” to generate rectangle easily. So we just use height*length to get the area of the rectangle.

Finally, we need to deal with the end boundary. We can just add a height 0 to the end of heights which can make sure that all previous heights were checked when we end the for loop.

Example Interview Problem 2:

This problem is from LeetCode 42. Trapping Rain Water.

The idea is similar with problem 1. The differences are:

• Use a decreasing stack.
• A little different operation when popping a element.

Conclusion

The monotonic stack is a very useful data structure and appearing in many interview problems. The most difficult part is to know whether a problem can be solved by this data structure or not.

We need to remember the three characters to help us think about that:

1. It is a “range queries in an array” problem.
2. The minima/maxima element or the monotonic order of elements in a range is useful to get answer of every range query.
3. When a element is popped from the monotonic stack, it will never be used again.
