A Collection of Docker Images To Solve All Your Debugging Needs
Whether you’re debugging networking, databases, your application code, or anything else, these images will be all you need to get it done
Whenever I troubleshoot anything container-related, I look for a good container image containing the right tools to troubleshoot and/or solve the problem. However, finding such an image, or assembling my own, is time-consuming and honestly just way too much effort.
So, to save you and me the hassle of finding or building such image(s), here’s a list of container images that will satisfy all the troubleshooting needs.
The Images
While building a “Swiss army knife container image” might seem like a good idea, there are always more things to add, and at some point, such an image becomes too big and hard to maintain.
A better option is to use an image such as infuser. infuser is built around tea CLI, which automatically installs any tool that you invoke. Let's say you run curl in a container, but it's not installed. No problem, tea will first install it and then invoke your command:
docker run --rm -it ghcr.io/teaxyz/infuser
...
# curl is not installed...
tea $ curl https://google.com
# installed: ~/.tea/curl.se/ca-certs/v2023.5.30
# installed: ~/.tea/curl.se/v8.2.1
# installed: ~/.tea/openssl.org/v1.1.1u
<HTML><HEAD><meta http-equiv="content-type" content="text/html;charset=utf-8">
<TITLE>301 Moved</TITLE></HEAD><BODY>
<H1>301 Moved</H1>
The document has moved
<A HREF="https://www.google.com/">here</A>.
</BODY></HTML>
# ... but worked anyway!
tea $If you’d rather have an image with everything preinstalled, yet you’re too lazy to write a Dockerfile and build the image, then you can use apko.kontain.me registry. This registry allows you to build an image with a specified set of packages simply by pulling it. Here’s the code:
docker run -it --rm apko.kontain.me/busybox/curl
Unable to find image 'apko.kontain.me/busybox/curl' locally
latest: Pulling from busybox/curl
d057dc95df58: Pull complete
Digest: sha256:48ac8175f9551bc96f7229d6c91e163d2b5948b2e80cb26ee8c95e68071ddbe1
Status: Downloaded newer image for apko.kontain.me/busybox/curl:latest
3add74404ade:/# curl
curl: try 'curl --help' for more informationWhen you pull from this registry, each component of the URL is interpreted as a package that will be added to the image ( apko.kontain.me/[package]/[package]/...), so all you need to do is make a list of packages and pull.
Alternatively, if you’re a fan of Nix, you can do the same with the nixery.dev registry. Here’s how to use that:
docker run -it --rm nixery.dev/shell/curl bash
Unable to find image 'nixery.dev/shell/curl:latest' locally
latest: Pulling from shell/curl
bf36edf1bbb6: Pull complete
...
bf30a3da102a: Pull complete
Digest: sha256:d99f1b56330831ee4217e7eb403bc667279f55f28660ef686daff653ac1a6561
Status: Downloaded newer image for nixery.dev/shell/curl:latest
bash-5.2# curl
curl: try 'curl --help' for more informationAs for more specialized tools, if I need to troubleshoot anything network-related, I always reach for netshoot. It contains all the networking tools you might need. All you need to do is run the following:
docker run --rm -it nicolaka/netshoot
# OR
kubectl run tmp-shell --rm -i --tty --image nicolaka/netshootThe above images should satisfy your troubleshooting needs, but there are a couple of honorable mentions:
alpine-containertools — Image with common container tooling. Targeted at security assessment tools.- Koolkits — Language-specific container images that contain a (highly opinionated) set of tools for debugging applications running in Kubernetes pods. Intended for use with
kubectl debug. doks-debug or Digital Ocean Kubernetes Service debug image. Intended for debugging Kubernetes cluster. Contains lots of useful tools for debugging clusters, not only in Digital Ocean.- “Utils” image with different sets of tools. This one includes various database clients and MQ tools.
Getting The Most Out of Them
I’ve shown you a list of images for debugging, but you can use a couple of extra tricks to get the most out of them.
Let’s say you need to debug one particular Kubernetes node. You could write a Pod YAML definition and specify nodeSelector to get the debug Pod to run on the specific node, but that's too much effort. Instead, you can run the following:
kubectl run debug --rm -i --tty \
--image=... \
--overrides='{"spec": { "nodeSelector": {"kubernetes.io/hostname": "some-node"}}}' -- bashAlternatively, you can use kubectl debug, which is quite literally SSH into a node:
kubectl debug node/some-node -it --image=...
You can utilize --overrides flag for other things, e.g., to have the code pull a secret to test whether credentials are valid. Here’s what the code looks like:
kubectl run pull-test --rm -i --tty \
--image=... \
--image-pull-policy="Always" \
--overrides='{ "spec": { "template": { "spec": { "imagePullSecrets": [{"name": "some-pull-secret"}]}}}}'The following kubectl debug can also be used for debugging existing Pods:
# Create an example Pod:
kubectl run nginx --image=nginx --command -- sleep 1000
# Attach ephemeral debug container to it:
kubectl debug --target nginx --image=... -i nginx
# Targeting container "nginx". ...
# Defaulting debug container name to debugger-5dmp2.
# ...There are many more things you can do with kubectl debug, I recommend you check out the docs. You can also take a look at my older article on the topic:
Finding More
If the abovementioned tools aren’t what you’re looking for, then here are a couple more places to look for more images.
The official Kubernetes registry hosts many useful images that might be useful when troubleshooting. All the images are available in the GCP console. There, you can find things like kustomize image or etcd-related images.
Alternatively, all of these images are also listed in GitHub, where each directory contains images.yaml which lists image names and tags. For example, k8s-staging-etcdadm directory lists the abovementioned etcd images for etcd-backup, etcd-dump and etcd-manager.
You can explore registries if you’re more of a command-line person. Here’s the code to list the tags of particular images:
docker run --rm gcr.io/go-containerregistry/crane ls eu.gcr.io/k8s-artifacts-prod/kustomize/kustomize
sha256-05e12a3e5085902d3d1b99a0ce74d7d9cead0d8a0343df7f306db7b1616a27b5.sig
...
v3.10.0
v3.8.10
v3.8.7
...Or to list images for the whole registry:
docker run --rm -it --entrypoint "/busybox/sh" gcr.io/go-containerregistry/crane:debug
crane auth login -u <USERNAME> -p <PASSWORD> <SOME_REGISTRY>
# 2023/07/28 09:14:19 logged in via /root/.docker/config.json
crane catalog <SOME_REGISTRY>
# ...Nowadays, many production-grade images ship with just the bare minimum needed to run the application, which is great for security but not debugging. These images, however, usually have a debug version with a :debug tag that includes more tools.
Finally, sometimes you need a single specialized CLI tool, e.g., to connect to a database or troubleshoot a particular service. More often than not, these CLI tools ship with the image for the service itself. So, if you need psql to connect to the PostgreSQL database, for example, then just use the official postgres image. The same goes for redis-cli and redis, mongoexport and mongo image, etc.
The easiest way to find the relevant image is, in this case, to search for “official” or “verified” images on Docker Hub.
Closing Thoughts
Nowadays, when I need to debug something, I usually just reverse-search shell history for one of the invocations of earlier shown commands/images (CTRL+R + apko/ netshoot/ kubectl debug), which saves a lot of time, and hopefully, some of these images and commands will also save you time!
And while this article focused on debugging, I’m convinced that anything — not just debugging — can be solved with docker pull. And when I say anything, I really mean it. Rather than installing a million tools and applications, you can just run them with the following code:
alias curl="docker run --rm -it curlimages/curl:7.83.1"
curl --help
# Usage: curl [options...] <url>
# ...Want to Connect?
