Continuous Integration for ROS

Continous Integration is part of the Devops workflow where code is pushed into a pipeline that performs a series of tests before embarking on Continous Deployment. The Continous Integration step typically involves some form of testing minimally involving unit tests.

Let’s make it as minimal as possible, in order for a Continous Integration pipeline to ‘pass’ it has to be able to build the current ROS package in question. In order to do this, first create a .github/workflows/CI.yaml file in the github repository.

Method 1:

This ‘manually’ installs ROS into the workspace

name: ROS CI

on:
  push:
    branches:
      - main
  pull_request:
    branches:
      - main

jobs:
  build:
    runs-on: ubuntu-20.04
    env:
      ROS_CI_DESKTOP: "`lsb_release -cs`"
      ROS_DISTRO: noetic
    steps:
      - uses: actions/checkout@v2
        with:
          submodules: recursive
      - name: Download selected private repository dependencies
        run: |
          mkdir -p ~/catkin_ws/src
          cd ~/catkin_ws/src
          ssh-agent sh -c 'echo "${{ secrets.OTHER_ROS_PACKAGE }}" | ssh-add - && git clone [email protected]:Organisation/other-ros-package.git'
      - name: Install ROS
        run: |
            sudo sh -c "echo \"deb http://packages.ros.org/ros/ubuntu $ROS_CI_DESKTOP main\" > /etc/apt/sources.list.d/ros-latest.list"
            sudo apt-key adv --keyserver 'hkp://keyserver.ubuntu.com:80' --recv-key C1CF6E31E6BADE8868B172B4F42ED6FBAB17C654
            sudo apt-get update -qq
            sudo apt-get install dpkg
            sudo apt-get install -y python3-catkin-pkg
            sudo apt-get install -y python3-catkin-tools
            sudo apt-get install -y python3-osrf-pycommon
            sudo apt-get install -y python3-rosdep
            sudo apt-get install -y python3-wstool
            sudo apt-get install -y ros-cmake-modules
            sudo apt-get install -y ros-noetic-dwa-local-planner*
            sudo apt-get install -y ros-noetic-turtlesim
            sudo apt-get install -y ros-$ROS_DISTRO-catkin
            source /opt/ros/$ROS_DISTRO/setup.bash
      - name: Install ROS packages with rosdep
        run: |
          source /opt/ros/$ROS_DISTRO/setup.bash
          sudo rosdep init
          rosdep update
          ln -s $GITHUB_WORKSPACE ~/catkin_ws/src/robot
          cd ~/catkin_ws
          rosdep install --from-paths src --ignore-src -ry
      - name: catkin build
        run: |
          source /opt/ros/$ROS_DISTRO/setup.bash
          cd ~/catkin_ws
          catkin build --no-status
          source devel/setup.bash

Method 2:

This installs ROS using the ros-tooling/[email protected] action instead of ‘manually’ installing ROS.

name: ROS CI

on:
  push:
    branches:
      - main
  pull_request:
    branches:
      - main

jobs:
  build:
    runs-on: ubuntu-20.04
    env:
      ROS_CI_DESKTOP: "`lsb_release -cs`"
      ROS_DISTRO: noetic
    steps:
      - uses: actions/checkout@v2
        with:
          submodules: recursive
      - name: Download selected private repository dependencies
        run: |
          mkdir -p ~/catkin_ws/src
          cd ~/catkin_ws/src
          ssh-agent sh -c 'echo "${{ secrets.OTHER_ROS_PACKAGE }}" | ssh-add - && git clone [email protected]:Organisation/other-ros-package.git'- name: Install ROS- name: Install ROS
      - name: Install ROS
      - uses: ros-tooling/[email protected]
          with:
            required-ros-distributions: noetic
      - run: "source /opt/ros/noetic/setup.bash && rosnode --help"
      - name: Install ROS packages with rosdep
        run: |
          source /opt/ros/$ROS_DISTRO/setup.bash
          sudo rosdep init
          rosdep update
          ln -s $GITHUB_WORKSPACE ~/catkin_ws/src/robot
          cd ~/catkin_ws
          rosdep install --from-paths src --ignore-src -ry
      - name: catkin build
        run: |
          source /opt/ros/$ROS_DISTRO/setup.bash
          cd ~/catkin_ws
          catkin build --no-status
          source devel/setup.bash

Method 3:

This method encapsulates everything into a docker file and builds that docker file instead

name: ROS CI

on:
  push:
    branches:
      - main
  pull_request:
    branches:
      - main

jobs:
  build-docker-image:
    name: Install ROS
    runs-on: ubuntu-20.04
    steps:
      - name: Download selected private repository dependencies
        run: |
          mkdir -p ~/catkin_ws/src
          cd ~/catkin_ws/src
          ssh-agent sh -c 'echo "${{ secrets.OTHER_ROS_PACKAGE }}" | ssh-add - && git clone [email protected]:Organisation/other-ros-package.git'
      - uses: actions/checkout@v2
      - name: Build Image
        uses: docker/build-push-action@v2
        with:
          file: ./Dockerfile
          push: false

The dockerfile should look like this:

# Contens of Dockerfile

FROM ros:noetic

# Copy catkin_ws repositories into this Docker Environment
COPY robot /root/catkin_ws/src/robot
COPY other-ros-package /root/catkin_ws/src/other-ros-package

SHELL ["bash", "-c"]

# add install deps
RUN apt-get update && apt-get install git -y

# https://github.com/docker/build-push-action/issues/504
ARG DEBIAN_FRONTEND=noninteractive

# install dependencies
RUN  cd /root/catkin_ws && \
  apt-get update && \
  apt install python3-catkin-tools -y && \
  rosdep update && \
  rosdep install --from-paths src --ignore-src -yr

# build repo
RUN . /ros_entrypoint.sh && cd /root/catkin_ws && \
  catkin build --cmake-args -DCMAKE_BUILD_TYPE=Release && \
  sed -i '$isource "/root/catkin_ws/devel/setup.bash"' /ros_entrypoint.sh

ENTRYPOINT ["/ros_entrypoint.sh"]
CMD ["bash"]

These are 3 ways to perform (basic) CI on Github actions with catkin build in order to check if the package is able to build. Cheerios~
